    SFP - 25G - SR - S Cisco SFP Modules 25 Gigabit Optical Modules

    SFP - 25G - SR - S= - Cisco 25 Gigabit Optical Modules best seal instock

    The Cisco® 25GBASE SFP28 (Small Form-Factor Pluggable) portfolio offers customers a wide variety of high-density and low-power 25 Gigabit Ethernet connectivity options for data center and high-performance computing networks applications. The 25G Modules are based on SFP28 form factor.


    Cisco 25G Modules provide these highlights:

    •Interoperable with other IEEE-compliant 25G interfaces where applicable

    •Certified and tested on Cisco SFP28 ports for superior performance, quality, and reliability

    •High-speed connectivity compliant to IEEE 802.3by and IEEE 802.3cc

    SFP-25G-SR-S= Specification

    DescriptionCisco 25GBASE-SR SFP28 Module for MMF
    25G Port cabling specifications
    Cable Distance70/100m (OM3/OM4)
    Max Power Consumption (W)1.2
    Pull Tab ColorBeige
    SFP28 port cabling specifications
    Wavelength (nm)850
    Cable TypeMMF
    Core Size (Microns)50.0
    Modal Bandwidth

    2000 (OM3)

    4700 (OM4)

    Cable Distance

    70m

    100m

    Optical transmit and receive specifications
    Type25GBASE-SR 850nm MMF
    Transmit Power (dBm)

    Max:+2.4

    Min:-8.4

    Receive Power (dBm)

    Max:+2.4

    Min:-10.3

    Transmit and Receive Wavelength (nm)840 to 860
    Environmental Conditions and Power Requirements
    Commercial temperature0 to 70°C (32 to 158°F)
    Storage temperature-40 to 85°C (-40 to 185°F)
    Regulatory and Standards compliance
    Standards

    •SFF-8402: SFP+ 28 Gb/s 1x Pluggable Transceiver Solution (SFP28) - Rev 1.0 March 30, 2014

    •SFF-8472: Diagnostic Monitoring Interface for Optical Transceivers - Rev 12 August 29, 2014

    •IEEE 802.3- 2015 IEEE Standard for Ethernet

    •IEEE P802.3by- 2016 Amendment 2: Media Access Control Parameters, Physical Layers, and Management Parameters for 25 Gb/s Operation

    •IEEE P802.3cc - 2017 Amendment 11: Physical Layer and Management Parameters for Serial 25 Gb/s Ethernet Operation Over Single-Mode Fiber

    •RoHS 6

    Safety

    • Laser Class 1 21CFR-1040 LN#50 7/2001

    •Laser Class 1 IEC60825-1

    •Cable jacket of SFP copper modules is UL E116441 Compliant

    •SFP copper cables are ELV Compliant

    the comparison.

    Product CodeSFP-10/25G-CSR-S=SFP-10/25G-LR-S=SFP-25G-SR-S=
    DescriptionCisco 10/25GBASE-CSR SFP28 Module for MMFCisco 10/25GBASE-LR SFP28 Module for SMFCisco 25GBASE-SR SFP28 Module for MMF
    Cable Distance300/400m (OM3/OM4)10km70/100m (OM3/OM4)
    Max Power Consumption (W)1.21.31.2
    Pull Tab ColorPeachBlueBeige
    Wavelength (nm)8501310850
    Cable TypeMMFSMFMMF
    Core Size (Microns)50.0G.65250.0
    Modal Bandwidth

    2000 (OM3)

    4700 (OM4)

    2000 (OM3)

    4700 (OM4)
