WS-C2960CX-8PC-L Cisco Compact Switch 2960CX Layer 2 POE+ LAN Base - Managed

    Buy cheap WS-C2960CX-8PC-L Cisco Compact Switch 2960CX Layer 2 POE+ LAN Base - Managed from wholesalers

    Buy cheap WS-C2960CX-8PC-L Cisco Compact Switch 2960CX Layer 2 POE+ LAN Base - Managed from wholesalers
    • Buy cheap WS-C2960CX-8PC-L Cisco Compact Switch 2960CX Layer 2 POE+ LAN Base - Managed from wholesalers
    • Buy cheap WS-C2960CX-8PC-L Cisco Compact Switch 2960CX Layer 2 POE+ LAN Base - Managed from wholesalers
    • Buy cheap WS-C2960CX-8PC-L Cisco Compact Switch 2960CX Layer 2 POE+ LAN Base - Managed from wholesalers
    • Buy cheap WS-C2960CX-8PC-L Cisco Compact Switch 2960CX Layer 2 POE+ LAN Base - Managed from wholesalers
    • Buy cheap WS-C2960CX-8PC-L Cisco Compact Switch 2960CX Layer 2 POE+ LAN Base - Managed from wholesalers

    WS-C2960CX-8PC-L Cisco Compact Switch 2960CX Layer 2 POE+ LAN Base - Managed

    Ask Lasest Price
    Brand Name : CISCO
    Model Number : WS-C2960CX-8PC-L
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 50 UNITS/MONTH
    Delivery Time : 1-2 DAYS
    • Product Details
    • Company Profile

    WS-C2960CX-8PC-L Cisco Compact Switch 2960CX Layer 2 POE+ LAN Base - Managed

    WS-C2960CX-8PC-L Cisco Compact Switch 2960CX Layer 2 POE+ LAN Base - Managed


    WS-C2960CX-8PC-L Overview


    WS-C2960CX-8PC-L equips 8 Gigabit Ethernet POE+ ports with 2 x 1 Gigabit copper and 2 x 1 Gigabit SFP uplinks. The POE powers up to 30W/port and supplies total 124W POE budget which can power IP phones, IP Cam or other POE devices.


    WS-C2960CX-8PC-L Cisco Compact Switch 2960CX Layer 2 POE+ LAN Base - Managed

    WS-C2960CX-8PC-L Cisco Compact Switch 2960CX Layer 2 POE+ LAN Base - Managed

    WS-C2960CX-8PC-L Cisco Compact Switch 2960CX Layer 2 POE+ LAN Base - Managed

    WS-C2960CX-8PC-L Cisco Compact Switch 2960CX Layer 2 POE+ LAN Base - Managed


    WS-C2960CX-8PC-L Specification


    WS-2960CX-8PC-L Specification

    Ethernet Ports8 x 10/100/1000 Gigabit Ethernet
    PoE
    Output Ports
    8 PoE+
    Available
    PoE Power
    124W
    Uplinks

    2 x 1G copper plus

    2 x 1G SFP

    Default SoftwareLAN Base
    Forwarding Bandwidth12 Gbps
    Switching Bandwidth (full-duplex capacity)24 Gbps
    Flash memory128 MB
    Memory DRAM512 MB
    Max VLANs255
    VLAN IDs4000
    Maximum transmission unit (MTU)Up to 9000 bytes
    Jumbo frames9198 bytes
    Forwarding rate 64 Byte Packet17.9 mpps
    Power connectors

    - Customers can provide power to a switch by using the internal power supply.

    The connector is located at the back of the switch.

    The internal power supply is an autoranging unit

    - The internal power supply supports input voltages between 100 and 240VAC
    - Use the supplied AC power cord to connect the AC power connector to an AC power outlet

    Indicators

    Per-port status: Link integrity, disabled, activity, speed, full-duplex

    System status: System, link status, link duplex, link speed

    Dimensions
    (H x W x D)
    1.75 x 10.6 x 9.4 in (4.44 x 26.9 x 23.8 cm)
    Weight5.0 lb (2.27 Kg)
    Package Weight10.25 lb (4.65 Kg)
    Operating* temperature up to 5000 ft (1524 m)

    -5°C to +45°C

    (+23°F to +113°F)

    Operating* temperature up to 10,000 ft (3048 m)

    -5°C to +45°C

    (+23°F to +113°F)

    Storage temperature up to 15,000 ft (4572 m)

    -25°C to +70°C

    (-13°F to +158°F)

    Operating altitude

    Up to 3048 m

    (Up to 10,000 ft)

    Storage altitude

    Up to 4000 m

    (Up to 15,000 ft)

    Operating relative humidity5% to 95% noncondensing
    Storage relative humidity5% to 95% noncondensing
    Mean time between failure (MTBF)569,530

    Main Features
    • Switch
    • managed
    • 8 x 10/100/1000 (PoE+) + 2 x SFP + 2 x 10/100/1000
    • desktop
    • rack-mountable
    • DIN rail mountable
    • wall-mountable
    • PoE+ (124 W)

    The Cisco Catalyst Compact Switches easily expand your Catalyst switching infrastructure outside the wiring closet to enable workspaces, extend wireless LANs, and connect PoE devices. These fan-less, small form-factor switches are ideal for space-constrained deployments where multiple cable runs would be challenging.

    The Cisco Catalyst 2960-CX compact switches help optimize network deployments. These Gigabit Ethernet (GbE) managed switches are ideal for high-speed data connectivity, Wi-Fi backhaul, and Power over Ethernet (PoE) connectivity in places where space is at a premium. With a single copper or fiber cable from the wiring closet, Catalyst compact switches enable IP connectivity for devices such as IP phones, wireless access points, surveillance cameras, PCs, and video endpoints.

    With their quiet, fanless design and compact footprint, these switches offer flexible mounting options and open up a variety of network design and connectivity options. Use them in offices, classrooms, hotels, retail stores, and other enterprise and branch locations. The setup allows for shorter cable runs from the compact switches, allowing for flexibility in space redesign and growth as the devices join the network - this eliminating the need for expensive and inflexible cabling infrastructure.
