    475266A (ABIO) A Nokia AirScale High-capacity 5G System Module Plug-in Unit

    Ask Lasest Price
    Brand Name : Nokia
    Model Number : 475266A (ABIO)
    Certification : CE
    Payment Terms : T/T,Western Union
    Delivery Time : 1-3 Days
    • Product Details
    • Company Profile

    475266A (ABIO) A Nokia AirScale High-capacity 5G System Module Plug-in Unit

    Overview

    The 475266A (ABIO) is a Nokia AirScale high-capacity 5G system module plug-in unit . Its dimensions are 25 mm x 219 mm x 364 mm, it weighs 2.65 kg, and it operates within a temperature range of -5°C to +55°C. It also supports both LTE and 5G NR narrowband cells, including up to 48 cells in a 2T2R or 4T4R configuration.

    Key specifications
    • Throughput: 14 Gbps (downlink) / 7 Gbps (uplink)
    • RRC Users: 15,120
    • 5G NR Capacity: Up to 12 cells of 100 MHz bandwidth (wideband)
    • LTE/5G NR Narrowband Capacity: Up to 48 cells in a 2T2R or 4T4R configuration
    • mMIMO: 32DL/16UL layers
    • Dimensions: 25 mm (H) x 219 mm (W) x 364 mm (D)
    • Weight: 2.65 kg
    • Power Consumption:
      • Typical: 160W
      • Maximum: 270W
    • Operational Temperature: -5°C to +55°C
    • Environmental Protection: IP20, ETSI EN 300 019-1-3, class 3.1E
    • Fronthaul Interface: Supports eCPRI (10/25 Gbps), CPRI (up to 9.8 Gbps), and OBSAI (3/6 Gbps)
